DJI RTK Rod Module

Features

Simultaneously receives: GPS: L1 C/A, L2, L5; BEIDOU: B1, B2, B3; GLONASS: F1, F2; Galileo: E1, E5A, E5B

Positioning accuracy:

single point

Horizontal: 1.5m(RMS)

Vertical: 3.0m(RMS)

RTK

Horizontal: 1 cm + 1 ppm(RMS)

Vertical: 2 cm + 1 ppm(RMS)

1 ppm: Accuracy will be 1mm less for every 1km increase in distance. For example, the horizontal accuracy is 1.1 cm when the receiving end is 1 km from the base station.

Ingress Protection Rating: IP65

Operating Temperature: -20° to 55°C (4° to 131°F)
